PCX- Safe And Reliable Operation With Small Area Fully Automated Vertical Rotary Parking System
Description
Rotary parking system is a kind of circular parking equipment similar to the carousel, access vehicles through all the rotation of the platform, there are generally 8 parking spaces,10 parking spaces,12 parking spaces and other types.
Rotary parking system is one of the most space-saving systems that allows you to park up to 16 SUVs or 20 sedans in only 2 conventional parking spaces. The system is independent, no parking attendant is required. By inputting a space code or swiping a pre-assigned card, the system can recognize your vehicle automatically and find the faster path to deliver your vehicle down to ground either clockwise or counterclockwise.
Product advantages
1) covers an area of small; two berths area can stop 6-10 vehicles.
2) The decoration can be added only roof, fire hydrants available.
3) Low prices, foundation, external decoration, fire and other small investment,
short construction periods.
4) Use automatic control, safe and reliable operation.
Technical parameters
| Item | Parameters |
| Type | Vertical Rotary |
| Levels of system | 5 |
| Paring Spaces | 8 |
Size of car
(L*W*H) | 5300*1900*1550mm
5300*1900*1950mm |
| Car Weight | 2000kg / 2350kg |
| Drive motor | 5.5kw |
| Rotating Speed | 4.4/min |
| Parking time | 60S |
| Drive Mode | Motor + Chain |
| Control | PLC type (basic) |
| Control Method | Touch screen / Push button or IC card |
| Parking way | Forward in, Back out |
| Electricity | 3 phases 5 wires, 380V, 50HZ |
| Safety devices | 1.Car block device (Positioning)
2.Operation warning device (Warning light)
3.Car position detection device (Over length, over width detection)
4.Malfunction warning device
5.Man or car mistake entrance detection (Photoelectric switch protection devices);
6.Emergency brake device when electricity cut off;
7.Over current flow protection device
8.Key switch against wrong operation;
9.Wrong phase, shortage phase protection, motor over loading protection device;
10.Emergency stop button; |
Dimensions
Main Structures
Rotary parking system is composed of 7 basic structures
Foundation, Steel structure, Pallets, Transmission, Control System, Safety Protection Devices and other Auxiliary Devices;
Safety characteristics
Maintenance
To ensure proper and stable fuction of entire parking system in the long run, regular and periodic inspection & maintenance
are also of vital importance:
Notes
Packing & Delivery
